Debugging

CMDBsyncer provides several debug tools that let you inspect behavior at every stage of the pipeline — before anything is written to a target system.

--debug Flag

Most CLI commands accept a --debug flag. It does two things:

  • Raises exceptions instead of swallowing them, so you see the full stack trace on errors.
  • Sets the Python log level to DEBUG, giving you detailed output about HTTP requests, responses, and internal processing directly on the console.
./cmdbsyncer checkmk export_hosts myaccount --debug

This is the first tool to reach for when a sync is failing or producing unexpected results.

Debugging Rule Outcomes

Rules can produce complex outcomes across many hosts. To inspect exactly which rules matched and which attributes were set for a specific host, use --debug-rules:

./cmdbsyncer checkmk export_hosts myaccount --debug-rules=myhostname

This prints a detailed table showing:

  • Which rules were evaluated for the given host
  • Which conditions matched or did not match
  • The final attribute values that would be sent to the target

You can combine --debug-rules with --debug to also raise exceptions during the same run:

./cmdbsyncer checkmk export_hosts myaccount --debug-rules=myhostname --debug

Tip

Use show_hosts first to confirm the host name as it appears in the syncer database before passing it to --debug-rules.

Debug Page in the Web Interface

The same analysis is available in the GUI: open a host and switch to its Debug tab, or use the Debug entry and enter a hostname. Pick the target system (Checkmk, Netbox, Ansible, i-doit, VMware, Jira Cloud) and press Analyze.

The page shows:

  • Outcomes — what the export would do with this host
  • Filtered Labels — the attributes left after the filter and rewrite rules
  • Rules — one tab per rule group (filter, rewrite, actions, custom attributes, …). Each row tells whether the rule matched, which condition decided it, and what that single rule contributes to the outcome. A rule that matched but adds nothing new is marked as such, because an earlier rule already set the value.
  • Total outcome — shown below every rule group: the combined result of all its matching rules, which is what the export actually uses
  • Full Attribute List — all raw host labels before filtering

Inspecting Without Exporting

Some modules provide read-only commands to inspect what would be exported — without making any changes to the target system:

# List all hosts that would be exported to a Checkmk account
./cmdbsyncer checkmk show_hosts myaccount

# List all labels that would exist in Checkmk after the sync
./cmdbsyncer checkmk show_labels myaccount

# Show hosts present in Checkmk but missing in the syncer
./cmdbsyncer checkmk show_missing_hosts myaccount

Dry Run and Saving Requests

To test an export without applying any changes, use --dry-run. To save all planned API requests to a file for review or later replay, use --save-requests:

./cmdbsyncer checkmk export_hosts myaccount --dry-run
./cmdbsyncer checkmk export_hosts myaccount --save-requests

API Request Debugging

To see the raw HTTP requests and responses sent to external systems, enable debug mode either via the --debug flag (per run) or permanently via local_config.py:

config = {
    'LOG_LEVEL': 'DEBUG',
}

See the App Configuration for all available log settings.

Web Log

Every sync run creates an entry in the web-based log, accessible from the GUI under Log. The log shows:

  • Metrics per run (hosts processed, errors, duration)
  • Per-host errors, highlighted in red
  • Which account and command was involved

This is the most practical place to monitor ongoing syncs and spot problems without needing shell access.

→ Logging documentation

Advanced Rule Debugging

For development and deep troubleshooting, you can enable verbose condition matching output by setting ADVANCED_RULE_DEBUG in local_config.py:

config = {
    'ADVANCED_RULE_DEBUG': True,
}

When enabled, every condition evaluation prints whether it matched or not. This produces a lot of output and is intended for development use only.
